M4S-1.500W, SMA-Female, 0.8-2.2 GHz

$208.15
SKU M4S-1.500W
STOCK: 11

Description:
MECA's 4-way, M4S-1.500W, M-Series SMA-Female power divider/combiner with an average power rating of 75 watts and frequency of 0.8-2.2 GHz.

Dowload Spec Sheet

Quote Request:
For large quantities or special orders, submit a quote request by viewing this product on www.e-MECA.com.

M4S-1.500W

M4S-1.500W

Notes:
1. All units rated for 75 watts maximum input power as a divider or balanced combiner with load VSWR
     of 1.20:1 or better.To calculate the combining rated power the following formula is used:
     (rated input power of divider * 5%) / "N" # of input channels = max input at each port for combining
2. All output/power combiner ports are in-phase (0° difference).
3. 50 ohm nominal impedance standard.
4. Operating temperature from -55°C to +85°C.

5. See application note MAP-801
