LPR24310-1.700VWWP, Female, 0.698-2.7 GHz

$272.55
SKU LPR24310-1.700VWWP
STOCK: 5

Description:
MECA line of high-power capable (700 watts) low PIM power splitters covering all wireless frequencies from 0.698 - 2.700 GHz. Available in 2-way configurations fitted with 4.3/10.0 Female Weatherproof connectors at all ports. Indoor or Outdoor use (IP67).

Dowload Spec Sheet

Quote Request:
For large quantities or special orders, submit a quote request by viewing this product on www.e-MECA.com.

Notes:
1. -161 dBc Typical With 2 X 20 Watt tones Verfied at 1900 MHz (< -153 dBc)@25ºC.
2. All units rated for maximum power with load VSWR of 1.20:1 or better.
3. All output/power combiner ports are in-phase (0° difference).
4. 50 ohm nominal impedance standard.
5. Operating temperature from -55°C to +85°C.
